Fiber braided hydraulic hose (wrapped cover/smooth cover)

SAE 100R3

(wrapped cover/smooth cover)

CONSTRUCTION:

This hose consists of an inner tube of oil-resistant synthetic rubber, two wire braids reinforcement, and an oil- and weather-resistant synthetic rubber cover.

APPLICATIONS:

Hose range suitable to carry hydraulic fluids, such as glycol, mineral oils, emulsion, hydrocarbons, etc.

WORKING TEMPERATURE:

From -40°C up to +100°C

Inquiry More

SAE 100R6

(wrapped cover/smooth cover)

HOSE CONSTRUCTION:

Tube: oil resistant synthetic rubber

Reinforcement: one textile braid wire braid

Cover: abrasion, ozone and weather resistant synthetic rubber

Temperature range (medium): -40°Cto +121°C

Inquiry More

SAE 100R7

STRUCTURE AND CAPABILITY:

This kinds of hose is made of inner tube ( Nylon ), reinforcement (High Pressure Synthetic Fiber ) , and cover ( High Flexibility Nylon or Thermoplastic ) . lt is lightweight,flexible and the inner tube is very smooth. With few loss of pressure, the hose resistance of themedium flowing is small, and it also owns a fine performance of anti-chemical and impulse.

APPLICATION:

Automobile,Engineering Machinery, Lathe, Agriculture Machine,Mining, Spurtingthe Oil Paint, Avigation & Spaceflight, Cooling and other Hydraulic Control System.

Inquiry More

SAE 100R8

CONSTRUCTION:

This kind of hose is made of Inner Tube (Nylon), reinforcement (High Flexibility Nylon or Thetmoplastic). It is Lightweight, Flexibility, and the inner tube is vety smooth. With a few loss of Pressure, the hose resistance of the Medium flowing is small, and it also owns a fine performance of Anti-chemical and Impulse.

Application :

Automobile, Engineering Machinery, Lathe,Agriculture Machine, Mining, Spurting the Oil Paint, Avigation&Spacefight, Cooling and other Hydraulic Control System.

WORKING TEMPERATURE: From -40°C up to +100°C

COLOUR: BLACK,ORANGE,BLUE
